High Speed , High Quality Direct to Fabric Digital Textile Printer
Specification
With a Massive Production Capacity of 9000 sqm/day
Our latest high-performance machine, the METRO NXT, has a great production capability of up to 9,000 sqm/day, considerably reducing the pressure associated with long industrial production runs in a short time. It comes with upto 32 Industrial Grade Kyocera Print Heads and delivers sharp quality output using ColorJet recommended inks available in the configuration of 8 Colors options.
METRO NXT, from the house of ColorJet - Best Indian textile printing company works on the technology of Drop-on-demand, Piezoelectric Inkjet that prints up to the high quality of 600x2400 DPI with the option of up to 8 colors and up to 32 heads. It offers the convenience of varied file formats including JPEG, TIFF, BMP, PDF (RGB/CMYK). METRO, our high-speed fabric printing machine is preloaded with the ColorJet edition of NeoStampa software.
METRO NXT |
|||||
|
CONFIGURATION |
HA8166 |
HA8326 |
|||
|---|---|---|---|---|---|
| Printing Technology |
Drop-on-demand, Piezo Electric Inkjet |
||||
| No. of Print Heads |
16 - 600 DPI |
32 - 600 DPI |
|||
| No. of Rows |
2 Rows |
4 Rows |
|||
| Print Heads | Type |
Industrial Grade Jetting Assemblies |
|||
| Resolution |
Upto 2400 DPI |
||||
| Height Adjustment |
upto 30mm |
||||
| CleaningMethod |
Pressure Purge and Wiping |
||||
| Wetting Control |
Piezoelectric Actuators |
||||
| Inks | Types |
Reactive/Disperse/Acid |
|||
| No of colors |
8 |
8 |
|||
| Supply |
10 Ltr, Bulk ink Supply System with inline degassing |
||||
| Fabric | Types |
Cotton,Viscose,Polyester,Polyamide,Silk,Wool |
|||
| Max.Thickness |
Upto 10mm |
||||
| Max.Width |
1850 mm |
||||
| Roll Width |
400mm |
||||
| Fabric Drying System |
Infrared Heaters |
||||
| Printing Interface |
USB 3.1 |
||||
| RIP Software Supported |
NeoStampa (Colorjet Editions) |
||||
| File Format |
JPEG, TIFF, BMP/PDF (RGB, CMYK) |
||||
| Power Requirements(Machine + Feeder) |
220 V, 14KW Single / Three phase load distribution, 50Hz |
||||
| Operating Conditions |
Temperature: 24°C ± 4°C Humidity: 60% ± 10% RH |
||||
| Printer Dimension / Net Weight |
4898 x 2250 x 1850 mm (LxWxH) / 3250 Kg Approx. |
||||
| Dryer Dimension / Net Weight |
2550 x 2050 x 1255 mm (LxWxH) / 700 Kg. Approx. /48KW |
||||
| Feeder Dimension / Net Weight |
2482 x 820 x 1160 mm (LxWxH) / 720 Kg Approx. |
||||
| Speed In Sq. Meter/Hrs) |
Print DPI |
Passes |
HA8166 |
HA8326 |
|
| Mode 1 |
|
1 |
400 |
900 |
|
| Mode 2 |
|
2 |
240 |
454 |
|
| Mode 3 |
600 x 1800 |
3 |
150 |
302 |
|
Printer Highlights
EFFICIENT INK SUPPLY SYSTEM
Sufficient ink supply to prevent ink starvation while printing at high-speed
HEAD CRASH PROTECTIVE SYSTEM:
To help protect the head from any obstruction during carriage movement
LINEAR MOTOR:
For precise ink jetting at high speeds & smooth carriage movement
GOLD PLATED METAL ENCODER:
More precise ink jetting even at high speeds results in precision printing
MODULAR FEEDING SYSTEM:
To incorporate large size rolls for continuous printing
ON DEMAND CAPPING & WIPING SYSTEM USING HMI SCREEN:
To keep inks from drying in the print head & remove debris
5 STAGES WATER EFFICIENT BELT CLEANING SYSTEM:
For easy belt wash & Jet cleaning, with no blockage due to lint or dust
