OVERVIEW
Eco-Friendly Digital Textile Printer with Pigment Inks.
TXF is 1.6 meters direct to fabric eco-friendly digital textile printer with mainly pigment inks. The uniqueness of TXF is that it is ideally suited for producing fine prints for the connoisseur. It requires lesser investment and leads to increased profitability. Maximum creativity with minimum space occupied to create unique designs that would be difficult to copy on other printers. TXF is an eco-friendly waterless fabric printing machine from the house of ColorJet. It is designed to print directly on various types of natural and synthetic fabrics. The adhesive belt cleaning system is equipped with water jets and a brush roller to wash off excess ink & lint and a super absorbent roller to ensure removal of residual droplets.
SPECIFICATION
TXF works on the technology of Drop-on-demand, Piezoelectric Inkjet that prints up to the high quality of 720x1440 DPI with the option of 8 colours and 2 print heads. It mainly uses pigment inks, however, it is compatible with other inks as well, like reactive, disperse, and acid. This waterless eco-friendly fabric printing machine offers a speed of up to 24 square meters per hour. It offers the convenience of varied file formats including JPEG, TIFF, BMP, PDF (RGB/CMYK). The touch screen operating interface makes it easily operable.
TXF |
|||||||
|
Models
|
TXF
|
||||||
| Printing Technology |
Drop-on-demand, Piezo electric inkjet
|
||||||
| No. of Print Heads |
2
|
||||||
| Print Head | Type |
Precision Grade Jetting Assemblies
|
|||||
| Resolution |
Maximum Up to 1440 dpi
|
||||||
| Height |
5mm auto adjustable
|
||||||
| Cleaning Method |
Auto Suction
|
||||||
| Wetting Control |
Piezoelectric Actuations
|
||||||
| Ink | Types |
Acid / Disperse / Pigment / Reactive water based Inks
|
|||||
| No of colors |
4/8 Colors
|
||||||
| Supply |
1.4 Ltr. Ink Supply System
|
||||||
| Fabric | Type |
Cotton, Cellulosic, Polyester, Polyamide, Silk, Wool
|
|||||
| Max.Thickness |
5 mm
|
||||||
| Max.Width |
1600 mm
|
||||||
| Roll Diameter |
450 mm
|
||||||
| Fabric Drying System |
Infrared heaters with Blower Fans
|
||||||
| Operating Interface |
Touch Screen
|
||||||
| Printing Interface |
High speed Ethernet
|
||||||
| RIP Software Supported |
ErgoSoft ( Colorjet Edition)
|
||||||
| File Format |
JPEG, TIFF, BMP/RGB, CMYK
|
||||||
| Power Supply |
220 V, 35 A Single/Three phase load distribution, 50Hz,
|
||||||
| Working Condition |
Temperature 20-28C, Humidity 60-70% RH - Non-Condense
|
||||||
| Outer Dimension / Weight |
3437 mm x 1834 mm x 1426 mm (LxWxH) / 1600 Kg Approx.
|
||||||
|
Speed
(In Sq. Meter/Hrs) |
Printing DPI
|
Passes
|
TXF-4C
|
||||
|
Mode 1
|
|
5
|
24
|
||||
|
Mode 2
|
720x720
|
6
|
20
|
||||
|
Mode 3
|
720x1440
|
9
|
14
|
||||
APPLICATIONS
TXF is the go-to direct to fabric printing machine for a variety of applications. It gives unique designs and is used to print apparel as well as home furnishing products. TXF is able to print on cotton, cellulosic, polyester, polyamide, silk, wool, and various other blended and non-blended fabrics. This eco-friendly digital textile printer is used to print sarees, bedsheets, skirts, pillows, and various other applications.
Sarees
Bedsheet
Skirt
Pillows
PRODUCT VIDEO
Product video will be uploaded soon...
