Delivering the Sharpest Solvent Prints Ever
Specification
Introducing the SoniQ Aqua, a game-changing 3.2-meter HQ Solvent Printer engineered to redefine the standards in both indoor and outdoor signage production.
With 4/8 high-speed KM heads, it offers unmatched upgradability, ensuring future-proof performance. Delivering stunning quality at 2130 sqft. /hr (8 Heads), it's perfect for indoor and outdoor needs. Its features streamline workflows and boost productivity, making it the ultimate solution for large format print businesses.
SONIQ AUQA |
|||||
| Model |
SC4428 |
SC8428 |
|||
| Printing Technology |
Drop-on-demand, Piezo electric inkjet |
||||
| Print Heads |
Konica Minolta Aqua |
||||
| No. of Print Heads |
4 |
8 |
|||
| Media | Width |
3300 mm (129 in.) |
|||
| Thickness |
Maximum 3.0 mm (120 mil )with liner (flexible) |
||||
| Roll Outer Diameter |
Maximum 300mm (12inch), 50.8 (2 in) |
||||
| Roll Weight |
Maximum 90 kgs |
||||
| Core Diameter |
76.2mm (3 inch) |
||||
| Types |
SAV, PAV Banner, Backlite Film, Window Film, Fabric (Solvent Base) |
||||
| Printing Width |
Maximum 3200mm (126 inch.) |
||||
| Inks | Types |
Solvent/Mild Solvent inks |
|||
| Color |
4 Colors (CMYK) |
||||
| Printing Resolution (dots per inch) |
Maximum up to 1440 dpi |
||||
| Distance Accuracy |
Error of less than ±0.3 % of distance travelled, or ±0.3 mm, whichever is greater |
||||
| Media Heating System |
Pre-heater and post-heater, setting range for the preset temprature: 30 to 60℃. Dryer setting range for the preset temperature : 30 to 60℃ |
||||
| Connectivity |
High speed USB 3.0 or more |
||||
| Power Requirements (Peak) |
AC 220 V ±10%, 20 A, 50/60 Hz |
||||
| Dimensions ( Printer only) |
4689mm X 1079mm X 1571mm(WxLxH) |
||||
| RIP Software |
ColorJet Edition RIP |
||||
| Weight |
Net Weight : 550 KG, Gross Weight : 742 KG |
||||
| Environmental | Power ON |
Temperature: 18 to 28℃ Humidity: 20 to 40%RH (non-condensing) |
|||
| Power OFF |
Temperature: 5 to 40℃ Humidity: 20 to 80%RH (non-condensing) |
||||
| Speed (In Sq. Meter/Hrs) |
Print DPI |
Passes |
Sq Mtrs/Hr (4 Heads) |
Sq Feet/Hr (8 Heads) |
|
| Mode 1 |
540x720 |
2 |
1050 |
2130 |
|
| Mode 2 |
540x1080 |
3 |
700 |
1410 |
|
| Mode 3 |
540x1440 |
4 |
525 |
1050 |
|
| Mode 4 |
540x1080 |
6 |
350 |
700 |
|
| Mode 5 |
540x1440 |
8 |
260 |
500 |
|
